1/2″ x 6″ Galvanized And Stainless Steel Lag Eye Bolt ENZE2416.11
- High Strength: Mechanical Test Load Fx: 9.6KN, Fy:7.8KN
- Process: Forging, threading
- Size: ø16 L=245mm
Specification
| Part No. | Size(mm) | Length(mm) | Thread length(mm) | Weight(KG) | Test load Fx(KN) | Test load Fy(KN) | ETIM CLASS |
| ENZE2416.11 | ø16 | 245 | 90 | 0.44 | 9.6 | 7.8 | EC000092 |
Other available sizes:
1/2″ x 4″
Material
The lag eye bolt ENZE2416.11 is made of two materials: steel, grade S355JO(EN10025-2), and 316 stainless steel.
Surface Treatment
Galvanized & stainless steel lag eye bolts are durable in harsh environments. Free from sharp burrs, zinc drips, or spikes
Packing
| Package | pieces | Length(mm) | Width(mm) | Height(mm) | Weight(KG) | Volume(m³) |
| Carton | 20 | 200 | 200 | 160 | 8.8 | 0.0064 |
| Pallet | 2000 | 1200 | 800 | 780 | 880 | 0.75 |
